How Much Does a Control4 Smart Home Cost

A smart home is a connected home and we use Control4 as our smart home platform of choice to make your home come together.

A lot of people ask us how much a smart home will cost and while the costs can vary hugely depending on each customer’s requirements we felt it would be useful for prospective clients to have a budget to work to so when you look to get in touch you have a much better idea of what a bespoke quotation may come to.

It’s important to note that there are costs which we would consider Control4 specific which is what this blog article is designed to cover and then many costs which are specific to smart homes but not just because you’ve chosen to install a Control4 automation system to control it.

When thinking about smart home, it’s important to consider all eventualities even if you can’t afford to fit the equipment initially. That’s why we are huge fans of pre-wiring homes for the future. If you have a wire you have an option, no wires means no options (or at the very least a big bill to retro fit them).
Afterall the most expensive cable is the one you don’t put in!

We would encourage anyone who is looking to do a Control4 smart home to speak to us about getting a bespoke quotation as there are many variables to designing a home.

Control4 Making Technology Work Together

Other Costs to Consider outside of Control4 Products and Services
When designing a smart home there are lots of other costs to consider, many of which are not Control4 specific and thus not covered in this guide. However, we would look to cost these up as part of a bespoke package of works.

– System Design Fee’s
– First Cabling Installation
– First Fix Cabling
– Connection plates
– TV’s
– Cinema Systems
– Heating Integration
– Motorised Blinds and Curtains
– Rack and associated components
– CCTV and Security
– Second Fix Installation
– Configuration Fee’s
– Service and aftercare

These costs should be considered as additional costs to that of installing a Control4 Smart Home system.

So what does the Control4 Specific Element Cost
Further down this page, you’ll see what we would consider the Control4 specific costs to equipment various size homes with a Control4 smart home system.

Where we have outlined lighting costs we are working on the basis that you’d have a hybrid lighting system. This means that key rooms would have smart lighting and low-priority rooms would have traditional lighting.

All prices quoted are inclusive of VAT** but exclude the cost of installation, configuration and the costs of anything outlined above which are not Control4 specific but can be required to complete the installation.

** you might be able to take between 5 and 20% off some elements quoted if your home is a large-scale renovation or new build.

All prices are correct as of August 2022.

Single Room

Audio Visual and Remote Control Costs

This solution would provide you with a single room of discrete high-resolution audio using in-ceiling speakers and an on-wall subwoofer, the ability to control all of your smart devices i.e TV, Sky Box and Blu-Ray player from a single intuitive Control4 interface along with rock solid WiFi and Industry leading router and network switch.

The items listed below provide an illustration of the equipment required for a typical system in a single room i.e. lounge or kitchen

1 x Control4 Core 1 Room Automation Controller
1 x Triad One Zone Amplifier
4 x Triad IC82 ceiling speakers
1 x Control4 Neeo Remote Control
1 x Triad On-Wall Subwoofer with 300W Amplifier
1 x Araknis AN-110 router
1 x Araknis AN-510 wireless access points
1 x Araknis AN-210 8 port gigabit PoE switch

===
System cost £6310.00 inclusive of VAT
===

Lighting Control Infrastructure Costs

The items listed below provide an illustration of the equipment required for a typical Control4 lighting system in a single room allowing for 4 dimmable loads of lighting.

2 x Control4 dual load dimmers
2x Control4 premium face plates

===
System cost £515.00 inclusive of VAT
===

Total System Cost £6825.00 inclusive of VAT

3-4 Bedroom House

Audio Visual, Network and WiFi Infrastructure Costs

This solution provides discrete high-resolution audio streaming to four rooms, with one room having an on-wall subwoofer, the ability to control all of your smart devices from a single interface i.e. Neeo Hand Held Remote, rock-solid WiFi throughout the house and Industry leading networking and power management with surge protection.

The items listed below provide an illustration of the equipment required for a typical system in a 3 to 4 bed house.

1 x Control4 Core 3 Automation Controller
12 x Triad IC82 ceiling speakers
4 x Triad One Zone Amplifier
1 x Triad On-Wall Subwoofer with 300W Amplifiers
3 x Control4 Neeo Remote Controls
1 x Araknis AN-310 router
1 x Wattbox Rack Mount 8 Way PDU
4 x Araknis AN-510 wireless access points
1 x Araknis AN-210 24 port gigabit PoE switch

===
System cost £11,095 inclusive of VAT
===

Lighting Control Infrastructure Costs
The items listed below provide an illustration of the equipment required for a typical Control4 lighting system in a 3 bed house allowing for 16 dimmable loads, 4 non-dimmable internal circuits and 4 non-dimmable external lighting circuits.

1 x 5 Slot Control4 Panel with Terminal Blocks
2 x Control4 8 channel dimmer modules
1 x Control4 8 channel relay modules
1 x Control4 bus ethernet gateway
1 x Control4 48V bus power supply
1 x Control4 DIN rail 8 port ethernet switch
10 x Control4 wired configurable keypads
10 x Control4 premium face plates and button packs

===
System cost £7195.00 inclusive of VAT
===

Total System Cost £18290.00 inclusive of VAT

5-6 Bedroom House

Audio Visual, Network and WiFi Infrastructure Costs

This solution provides discrete high-resolution audio streaming to eight rooms, with two rooms having an on-wall subwoofer, the ability to control all of your smart devices from a single interface i.e. Neeo Hand Held Remote or In-Wall Touch pad, rock-solid WiFi throughout the house and Industry leading networking and power management with surge protection. We’ve also included a gate intercom as this is very popular for this size of home.

The items listed below provide an illustration of the equipment required for a typical system in a 5 to 6bed house.

1 x Control4 Core 5 Automation controller
5 x Control4 Neeo system remotes
1 x Triad 8-zone, 8 source audio matrix
1 x Triad 8-zone, 16 channel power amplifier
16 x Triad IC82 ceiling speakers
1 x 8″ In-Wall Touchpad
1 x Control4 DS2 Gate Intercom
2 x Triad On-Wall Subwoofer with 300W Amplifier
1 x Araknis AN-310 router
1 x Wattbox Rack Mount 8 Way PDU
8 x Araknis AN-510 wireless access points
1 x Araknis AN-210 24 port gigabit PoE switch
2 x Araknis AN-110 24 port gigabit switch

===
System cost £28,995.00 inclusive of VAT
===

Lighting control Infrastructure Costs
The items listed below provide an illustration of the equipment required for a typical Control4 lighting system in a 4 / 5 bed house allowing for 32 dimmable loads with a further 4 non-dimmable internal loads and 4 external non-dimmable loads.

1 x Pre wired lighting enclosure for 5 modules with RCBO breakers and isolator
4 x Control4 8 channel dimmer modules
1 x Control4 8 channel relay module
1 x Control4 bus ethernet gateway
1 x Control4 48V bus power supply
1 x Control4 DIN rail 8 port ethernet switch
20 x Control4 wired configurable keypads
20 x Control4 premium face plates

===
System cost £13,995.00 inclusive of VAT
===

Total System Cost £42,990.00 inclusive of VAT

6-8 Bedroom House

Audio Visual, Network and WiFi Infrastructure Costs

This solution uses Control4’s largest and most powerful automation controller. It’s capable of powering the sixteen zones of high-resolution audio streaming, 8 rooms of video distribution and source device control through hand held Neeo remotes for eight rooms, the ability to control of all of your smart devices from a a couple of in-wall touch pad controllers, rock solid whole house WiFi and Industry leading networking and power management with surge protection. Once again we’ve also included a gate intercom device.

The items listed below provide an illustration of the equipment required for a typical system in a 6 / 7 bed house.

1 x Control4 CA-10 Automation controller
8 x Control4 Neeo system remotes
1 x Triad 16-zone, 16 source audio matrix
2 x Triad 8-zone, 16 channel power amplifiers
24 x Triad IC82 ceiling speakers
4 x Triad IC82 DT stereo ceiling speakers
3 x Triad On-Wall Subwoofer with 300W Amplifier
2 x Control4 8″ In-Wall Touchpad Interfaces
1 x Control4 DS2 Gate Intercom
1 x Pulse Eight neo:X+ 4K video matrix kit with Baluns (8×8)
1 x Araknis AN-310 router
1 x Wattbox Rack Mount 8 Way PDU
10 x Araknis AN-510 wireless access points
2 x Araknis AN-210 24 port gigabit PoE switch
1 x Araknis AN-110 24 port gigabit switch

===
System cost £51,195.00 inclusive of VAT
===

Lighting control infrastructure Costs
The items listed below provide an illustration of the equipment required for a typical Control4 lighting system in a 6 / 7 bed house allowing for 56 dimmable loads with a further 4 non-dimmable internal loads and 4 non-dimmable external loads.

1 x Pre wired lighting enclosure for 9 modules with RCBO breakers and isolator
1 x Control4 bus ethernet gateway
1 x Control4 48V bus power supply
2 x Control4 DIN rail 8 port ethernet switches
7 x Control4 8 channel dimmer modules
2 x Control4 8 channel relay modules
30 x Control4 wired configurable keypads
30 x Control4 premium face plates and button packs

===
System cost £21,195.00 inclusive of VAT
===

Total System Cost £72,390.00 inclusive of VAT

As a Control4 Certified Showroom and winner of Control4’s dealer of excellence award in 2022 we are well placed to help you with your Control4 smart home project. Please get in contact to visit our Certified showroom to see how we can transform you dreams into reality.
